Wall Mounted Post Indicator Valve

Indicators posts display the disposition open shut of the gate valve behind a wall from a distance and are required on nrs gate valves in sprinkler service.

Wall mounted post indicator valve.

Post indicator valves ul listings and fm approvals download and print submittals from our website and see what i know to be true so many valves so many different names and so few factories. The kennedy valve indicator post comes with an l shaped handle which can be fitted with a secure lock. The post has a 12 diameter base with 3 4 bolt holes which can be mounted to a wall. Also indicator posts readily and clearly indicates whether the valve is open or shut.

Open left or right options. Brecco wall indicator post indicates if the valve is in the open or shut position. Loosen the telescoping barrel screw and adjust barrel to the ground level. 181 2 470mm 31 2 89mm field cut 11 16 17mm sleeve set screw upper stem square tube cotter pin lower stem square tube optional pipe sleeve.

Set the open and shut targets for the appropriate valve size. The 2945a post has a telescoping barrel and is adjustable to meet various trench depths. They provide a means to operate a buried or otherwise inaccessible valve. Cut the 1 square stem at a distance of 9 above the top of the barrel end.

For use with firelock nrs gate valves. Withstands up to 900 ft lb 1220nm of operating torque. Submittal manuals resource number downloads collection gate valves series 771 os y series 772 series 773 and series 774 submittal 10 92 download. Ability to open left or right.

It is operated by a hand wheel and used to operate a valve installed behind a wall. These systems usually have a lockable actuator which looks like a red metal steering wheel or a wrench handle on top of a post. Post flange to mount on a wall. The mueller wall mount inidcator post is used to operate a valve installed behind a wall and indicates if that valve is open or shut.

Sizes from 2 12 dn65 dn300. Dn350 non rising stem post indicator valves requiring 14 to 49 turns respectively to open. Telescoping post indicator field adjustment instructions 1. Series 773 firelock nrs wall post indicator.

Also known as piv indicator post i post ip post indicator or wall post a post indicator valve is a valve assembly used for the purpose of underground piping for water supply to fire protection systems such as sprinklers sprays foams deluges etc. The nibco indicator post is a wall type for operating non rising stem gate valves. Comes equipped with a 12 o d. If your valve says china on it than it s quite probable argco buys from the same factory that your brand product comes from.

Series 773 firelock nrs wall post indicator. Remove the top section from the indicator post assembly.
